Nash Bar

The Nash Bar is an advanced multi-color strobe and effect linear bar designed to deliver powerful, dynamic lighting with 3,500 lux of brightness at 1 meter. With 1,440 high-output LEDs across 16 pixel-mappable segments, it provides ultra-smooth full-spectrum color mixing. Its electronic strobe reaches speeds up to 20 Hz, producing bold strobe and pulse effects with precise control for creative impact.

Built with a durable sheet-metal housing and active cooling, the Nash Bar delivers reliable performance show after show. It supports multiple control modes—including DMX, sound-active, and auto programs—through 3-pin DMX and PowerCON connections. High-resolution dimming and advanced pixel-mapping give lighting designers complete flexibility to create detailed, custom effects, making the Nash Bar a versatile choice for impactful visual design.

What It Delivers :

• 3,500 Lux @ 1 Meter — bright output that cuts through ambient light.
• 1,440 LEDs Across 16 Segments — smooth, even color with full pixel control.
• DMX Pixel Mapping — fast programming for clean, customizable looks.
• 20 Hz Electronic Strobe — sharp, punchy hits for high-energy moments.
• 3-Pin DMX & PowerCON — reliable connections built for pro rigs.
• DMX, Auto & Sound Modes — flexible control for any show setup.

In the Box:

• 1 x Nash Bar
• 1 x Adjustable Yoke Arm with T-Handle Screws
• 1 x Edison to PowerCON Power Cable
• 1 x 3-Pin XLR DMX Cable
• 1 x User Manual
